Project: The Ore Sprint

Combining commands, events and timing into a game

150–180 minutesEnvironment: JDK 21, ordinary Paper 1.21.11, client of the same version. Server plugins are loaded by Paper; only explicitly labeled rule tests use main.Project integration and delivery

WHAT YOU WILL MAKE

A complete round of registration, timing, scoring and settlement

Connect the parts of the first seven lessons into an ore sprint race. The rules class manages status and scores, and the plug-in connects commands, events and timings; after the game ends, the scoring entrance is closed first, and then the results are read and the cleaning tasks are completed. Front Backpack: Lessons 31-37. The independent project name is OreRush, the package name is de.teacherma.orerush, and we continue to use Java21 and ordinary Paper1.21.11. This lesson can be completed in two sessions.

Before you start: It is recommended to complete Lessons 31–37 first

01 / 16

Before starting: first recognize the running position

The first 30 lessons lay the foundation for ordinary Java programs. At this stage, the code is connected to the Paper server: the Minecraft client is responsible for entering the world, the server loads the plug-in, and the events and commands hand over player actions to your methods.

This book uses JDK 21 and Paper 1.21.11, and the client version is also consistent. The latest version on the download page may have changed, select it by version number. This book uses normal plugin.yml and the Bukkit API; no claims are made to support Folia at this stage.

The short examples in the picture frame are partial fragments. Read the location description of this section first, and do not save each as a plug-in. The file name will be clearly given for the complete file; when the same file is divided into multiple segments, they will be connected by number, and the package name, import and outer class will only appear once.

  • Prediction: Write success conditions and expected messages first.
  • Run: After successful construction, install and restart on the dedicated local test server.
  • Verification: Ordinary players, management identities and consoles take corresponding paths respectively.

02 / 16

Make an appointment with the rules of the competition first

Before the game started, A Fang had already dug out a bag of coal and urged the referee to add points. The referee turned over the status card: you can only register during the assembly, and the scores will be recorded during the game. After the settlement, you can't modify the score of this round by swinging the pickaxe.

First write the rules as status changes: WAITING and other registrations, RUNNING to accept valid scoring, ENDING to freeze and settle. Pure Java class management rules, the Paper main class connects commands, events and tasks, and each side has checkable responsibilities.

Make an appointment with the rules of the game first
  1. Player registration to check scoresjoin and score
  2. Administrator starts and stopsstart and stop
  3. Scoring ContractWorld survival mode is specified and the event is not canceled

Four commands for players and teachers · See the instructions in this section for their positions

/orerush join     # Player registration
/orerush score    # Query the score of this bureau
/orerush start    # Teacher starts
/orerush stop     # Teacher cancels and clears registration
  • The three types of ores include ordinary ores and deep slate ores. Points are scored based on the number of blocks allowed to be destroyed, not the number of dropped items.
  • Only events in designated worlds, survival modes, and registered players are calculated.
  • Registration and scores will be cleared after one round; registration must be re-registered for the next round.

03 / 16

Status determines what can be done now

WAITING is like a gathering area, allowing registration; RUNNING is like a mine in a competition, allowing scoring; ENDING locks the scoring first, and then sorts out the results. State is not a sign written on the wall, but a value that is checked by the program before each action.

Three states: start, return to zero and return to waiting
  1. WAITINGRegistration is allowed, waiting to start
  2. RUNNINGOnly score points for registered players
  3. ENDINGStop scoring and read the results
TransitionTrigger
WAITING → RUNNINGStart
RUNNING → ENDINGTimer reaches zero
ENDING → WAITINGReset
RUNNING → WAITINGStop / reset

Extra points can only be added during the game. See the description of this section for the position.

if (state != State.RUNNING) return;
Checklist
ActionWAITINGRUNNINGENDING
RegistrationAllowRejectReject
StartSome people allow itRejectReject
Bonus pointsRejectOnly allowed after registrationReject
resetClearCancel and ClearClear after settlement

04 / 16

Registration list and score sharing player key

UUID is used as a key, and a score of 0 means that you have registered but have not yet scored. The absence of this key means that you have not registered, and the two cannot be confused. names is saved as the name during registration and is only used for result display; the program will not hold on to a Player object for a long time.

Registration list and score sharing player key
  1. The same UUIDName and score share identity key
  2. Initial 0 pointsCreated only after successful registration
  3. Name SnapshotOnly used for performance display

Avoid repeated registration and clearing · See the instructions in this section for the location

if (state != State.WAITING || scores.containsKey(id)) return false;
scores.put(id, 0);
return true;

Distinguish between unregistered and zero points. See the description in this section for the location.

Integer score = round.snapshot().get(id);
String message = score == null ? "You have not registered yet" : "Score of this game: " + score;

05 / 16

Filter events first and then calculate the ore score

A stone can also generate a destruction event, but it does not have to be given a diamond medal. The listener first filters the competition status, world and survival mode; the rules class then checks the registration. The material name is given to a pure Java method and gets 0, 3, 5 or 10.

Stop and think about it: Should you broadcast the leaderboard first when you finish, or leave the RUNNING state first? What if another mining event is received during settlement?

Filter events first and then calculate the ore score
  1. Filter eventsGame status, world, mode
  2. Obtain ore scoreIron 3, Gold 5, Diamond 10
  3. Write in those who have registeredNot registered or 0 points are not written in

Before entering the next step along the arrow, the conditions of the previous step must be met; the rejected branch returns early.

Unified score entrance · See the description in this section for the location

int points = GameRound.points(event.getBlock().getType().name());

Two types of deep slate ores must also be recognized. See the description in this section for their locations.

GameRound.points("DEEPSLATE_DIAMOND_ORE"); // 10
GameRound.points("DEEPSLATE_IRON_ORE");    // 3
GameRound.points("STONE");                 // 0

06 / 16

Only one task ticket is received per game

Repeated tasks are created only after successful start. GameRound.start refuses to start again, so if you press start twice, two referees will not appear, and the seconds will be reduced twice. Wait for 20 ticks for the first callback and then subtract 1.

Only one task ticket is received per game
  1. Start successfullyArrange only after the status check passes
  2. Every 20 ticksCallback an update
  3. The task is uniqueRefuse to start again

Check first and then create the task · See the instructions in this section for the location

if (!round.start(duration)) {
    sender.sendMessage("Cannot start now");
    return true;

}
// Called after passing runTaskTimer

The order and position in the callback are described in this section.

if (round.tick()) { finish(); return; }
int left = round.remaining();

07 / 16

Close the scoring first and then announce the results

The last tick changes the status to ENDING before calling finish. Cancel the task during settlement, read the score snapshot, display the scores from high to low, and finally clean up. Otherwise, when the referee calls for the second person, the first person may secretly dig another piece.

Turn off the scoring first and then announce the results
  1. Turn off scoringReturn to zero and enter ENDING
  2. Read snapshotSort by score and UUID
  3. Unified resetCancel the task and clear the office

The status changes in the rule class. See the description in this section for the location.

if (--remaining > 0) return false;
state = State.ENDING;
return true;

The score snapshot is not afraid of clearing the original table. See the description in this section for the location.

var result = round.snapshot();
round.reset();
// result The previous results are still retained and cannot be modified..
  • Tie scorers have the same score, and the display order is stably arranged with UUID strings. It is not claimed that the person who displays it first wins.
  • The results of this game are only broadcast, and the history is not saved; stop is a cancellation, and no awards are given.
  • Plug-in deactivation also cancels the task and clears the memory state.

08 / 16

Prepare two classes and two resource files

Create Gradle project OreRush, using build.gradle.kts from Lesson 31. Java files are placed in src/main/java/de/teacherma/orerush. The following two ymls are placed in src/main/resources. After the first startup, modify plugins/OreRush/config.yml, and it will take effect after stopping the server and restarting it.

Prepare two classes and two resource files
  1. GameRound.javaNumber rules and status
  2. OreRushPlugin.javaCommand events and scheduling
  3. Two ymlIdentity permissions and gameplay configuration

Complete plugin.yml · Complete file

name: OreRush
version: 1.0.0
main: de.teacherma.orerush.OreRushPlugin
api-version: '1.21.11'
author: TeacherMa
website: https://www.teacher-ma.de
commands:
  orerush:
    description: Sign up and manage ore sprint
    usage: /orerush <join|score|start|stop>
permissions:
  blockacademy.orerush.admin:
    default: op

Complete config.yml · Complete file

world: "world"
duration-seconds: 60

09 / 16

Complete competition rules class

Save the following completely as GameRound.java. This class does not import Paper and only handles status, UUIDs, and numbers; you will test it directly in Lesson 39 without having to start the game every time.

Complete competition rules class
  1. Registration contractOnly in WAITING and not repeated
  2. Start contractSomeone, legal duration, free
  3. Scoring ContractRegistered and scored positive points in the competition

Complete GameRound.java · This paragraph 1/2, sequential connection

package de.teacherma.orerush;
import java.util.HashMap;
import java.util.Map;
import java.util.UUID;
public final class GameRound {
    public enum State { WAITING, RUNNING, ENDING }
    private State state = State.WAITING;
    private int remaining;
    private final Map<UUID, Integer> scores = new HashMap<>();
    public State state() { return state; }
    public int remaining() { return remaining; }
    public boolean join(UUID id) {
        if (state != State.WAITING || scores.containsKey(id)) return false;
        scores.put(id, 0); return true;
    }
    public boolean start(int seconds) {
        if (state != State.WAITING || scores.isEmpty() || seconds < 1 || seconds > 3600)
            return false;
        scores.replaceAll((id, old) -> 0);
        remaining = seconds; state = State.RUNNING; return true;
    }
    public void add(UUID id, int points) {
        if (state == State.RUNNING && scores.containsKey(id) && points > 0)
            scores.computeIfPresent(id, (key, old) -> old + points);
    }

Complete GameRound.java · This paragraph 2/2, sequential connection

    public boolean tick() {
        if (state != State.RUNNING) return false;
        if (--remaining > 0) return false;
        state = State.ENDING; return true;
    }
    public Map<UUID, Integer> snapshot() { return Map.copyOf(scores); }
    public void reset() {
        state = State.WAITING; remaining = 0; scores.clear();
    }
    public static int points(String material) {
        if (material == null) return 0;
        return switch (material) {
            case "DIAMOND_ORE", "DEEPSLATE_DIAMOND_ORE" -> 10;
            case "GOLD_ORE", "DEEPSLATE_GOLD_ORE" -> 5;
            case "IRON_ORE", "DEEPSLATE_IRON_ORE" -> 3;
            default -> 0;
        };
    }
}

10 / 16

The first part of the main class of the competition

The next four pages synthesize OreRushPlugin.java in order. This page imports dependencies, declares shared status, and reads configuration; if the YAML itself cannot be read, the plug-in is disabled and the log is retained.

The first part of the main class of the competition
  1. Plug-in fieldA rule and a task
  2. Candidate ConfigurationType, Duration and World Verification
  3. Registration entranceOnly receive command events if the configuration is qualified

Main class part 1 · This paragraph 1/2, sequential connection

package de.teacherma.orerush;

import java.io.File;
import java.io.IOException;
import java.util.HashMap;
import java.util.Map;
import java.util.Objects;
import java.util.UUID;
import net.kyori.adventure.text.Component;
import org.bukkit.GameMode;
import org.bukkit.command.Command;
import org.bukkit.command.CommandSender;
import org.bukkit.configuration.InvalidConfigurationException;
import org.bukkit.configuration.file.YamlConfiguration;
import org.bukkit.entity.Player;
import org.bukkit.event.EventHandler;
import org.bukkit.event.EventPriority;
import org.bukkit.event.Listener;
import org.bukkit.event.block.BlockBreakEvent;
import org.bukkit.plugin.java.JavaPlugin;
import org.bukkit.scheduler.BukkitTask;

public final class OreRushPlugin extends JavaPlugin implements Listener {
    private final GameRound round = new GameRound();
    private final Map<UUID, String> names = new HashMap<>();

Main Class Part 1·This paragraph 2/2, sequential connection

    private BukkitTask task;
    private String worldName;
    private int duration;
    @Override
    public void onEnable() {
        saveDefaultConfig();
        var config = new YamlConfiguration();
        try { config.load(new File(getDataFolder(), "config.yml")); }
        catch (IOException | InvalidConfigurationException ex) {
            getLogger().log(java.util.logging.Level.SEVERE, "Configuration read failed", ex);
            getServer().getPluginManager().disablePlugin(this); return;
        }

11 / 16

Competition main class second part

Continue with the same file. Check the type and scope of the configuration, register commands and events. Join and score must be performed by the player; registration must also confirm the player's world and survival mode.

The second part of the main class of the competition
  1. joinPlayers register in designated worlds
  2. scoreCheck your own score
  3. start and stopManagement rights protection

Main class part 2·sequentially connected to the same source file

        worldName = config.getString("world", "");
        duration = config.getInt("duration-seconds", 0);
        if (!config.isString("world") || !config.isInt("duration-seconds")
                || getServer().getWorld(worldName) == null || duration < 1 || duration > 3600) {
            getLogger().severe("Invalid configuration: world Need to be loaded, duration-seconds Need to be 1 to 3600 integer");
            getServer().getPluginManager().disablePlugin(this); return;
        }
        Objects.requireNonNull(getCommand("orerush")).setExecutor(this);
        getServer().getPluginManager().registerEvents(this, this);
    }
    @Override
    public boolean onCommand(CommandSender sender, Command command,
                             String label, String[] args) {
        if (args.length != 1) { sender.sendMessage("/orerush join|score|start|stop"); return true; }
        String action = args[0];
        if (action.equals("join") || action.equals("score")) {
            if (!(sender instanceof Player p)) {
                sender.sendMessage("Please operate in the game to register and check scores."); return true;
            }
            UUID id = p.getUniqueId();
            if (action.equals("score")) {
                Integer score = round.snapshot().get(id);
                p.sendMessage(score == null ? "You have not registered yet" : "Score of this game: " + score);
            } else if (!p.getWorld().getName().equals(worldName)
                    || p.getGameMode() != GameMode.SURVIVAL) {
                p.sendMessage("Please use survival mode to register in the competition world");
            } else if (round.join(id)) {
                names.put(id, p.getName()); p.sendMessage("Registration successful, waiting for the teacher to start");
            } else p.sendMessage("Already registered, or the competition is in progress");
            return true;
        }

12 / 16

The third part of the main class of the competition

This paragraph deals with the teacher's start and stop. When start is rejected, no new tasks will be created; stop cancels the game and clears the registration. The scheduled callback only performs one subtraction and a small amount of message judgment.

The third part of the main class of the competition
  1. StartCreate a task after success
  2. CountdownBoth the first time and the interval are 20 ticks
  3. EventOnly send qualified materials into the rules

Main class part 3·sequentially connected to the same source file

        if (!action.equals("start") && !action.equals("stop")) {
            sender.sendMessage("Parameters can only be join, score, start, stop"); return true;
        }
        if (!sender.hasPermission("blockacademy.orerush.admin")) {
            sender.sendMessage("Only the teacher can start or stop the game"); return true;
        }
        if (action.equals("stop")) {
            reset(); announce("This office has been canceled and the registration has been cleared"); return true;
        }
        if (getServer().getWorld(worldName) == null || !round.start(duration)) {
            sender.sendMessage("Unable to start: Check world, registrants and race status"); return true;
        }
        announce("Ore sprint begins, total " + duration + " seconds!");
        task = getServer().getScheduler().runTaskTimer(this, () -> {
            if (round.tick()) { finish(); return; }
            int left = round.remaining();
            if (left % 10 == 0 || left <= 5) announce("Remaining " + left + " seconds");
        }, 20L, 20L);
        return true;
    }

13 / 16

The fourth part of the main class of competition

Complete the block events, performance sorting and cleaning methods, and finally close the main class. finish is only called by the zeroed tick, and all finishing paths can cancel the task; Map snapshot is used to read scores, and the original table is still managed by the rule class.

The fourth part of the main class of the competition
  1. SettlementRead independent score snapshot first
  2. BroadcastEven points also have a certain order
  3. Clean upTasks, registration, names are unified and concluded

Main Class Part 4·Sequentially connected to the same source file

    @EventHandler(priority = EventPriority.MONITOR, ignoreCancelled = true)
    public void onBreak(BlockBreakEvent event) {
        if (round.state() != GameRound.State.RUNNING) return;
        if (!event.getBlock().getWorld().getName().equals(worldName)) return;
        if (event.getPlayer().getGameMode() != GameMode.SURVIVAL) return;
        round.add(event.getPlayer().getUniqueId(),
                GameRound.points(event.getBlock().getType().name()));
    }
    private void finish() {
        if (task != null) task.cancel();
        task = null;
        announce("Time is up, settle the score of this game!");
        round.snapshot().entrySet().stream().sorted((a, b) -> {
            int order = Integer.compare(b.getValue(), a.getValue());
            return order != 0 ? order : a.getKey().toString().compareTo(b.getKey().toString());
        }).forEach(entry -> announce(names.getOrDefault(entry.getKey(), "Unknown player")
                + ": " + entry.getValue() + " points"));
        reset();
    }
    private void announce(String text) { getServer().broadcast(Component.text(text)); }
    private void reset() {
        if (task != null) task.cancel();
        task = null; round.reset(); names.clear();
    }
    @Override
    public void onDisable() { reset(); }
}

14 / 16

Complete the entire round from registration

Invite two students to sign up separately and let the teacher start. Alex digs a diamond and Steve digs two iron ores. The ending points should be 10 and 6 respectively. Do the fault route again: do not register, start again, continue digging after the end, and see if the score is blocked.

Complete the entire round from registration
  1. Alex Diamond10 points
  2. Steve iron ore two pieces6 points
  3. Dig again after finishingNo longer written to this office
Checklist
OperationExpected
start when no one signs upReject
Start or join again during the gameReject, do not superimpose tasks
Digging two types of Diamond Ores in survival mode10 points per block
Unregistered or other world miningNo scoring
Destruction is canceled by the protected plug-inNo scoring
Dig again after natural endNo points, need to re-register
Stop or stop serving during the gameTasks are cleared and results are not retained

15 / 16

Expansion challenges and own acceptance records

Leave the source code, actual running results and a problem record. Explain it in your own words first, and then run the verification; where the results are different from the predictions, they are often the most worthy of discussion.

Expansion tasks and clearance review
  1. Wooden PickaxeComplete a game completely
  2. Iron PickaxeModify score and retest
  3. Diamond PickaxeAdd read-only status query
  • Wooden Pickaxe: Make a test list for the three ores and their dark slate versions, confirming that ordinary stone is 0 points.
  • Iron Pickaxe: Complete a two-player game, repeat start, stop and restart tests, and record ten acceptance results.
  • Diamond Pickaxe: Design a team or combo, select only one new function; write down clearly when to add points and when to clean up, and then implement it.
  • Acceptance requirements: Complete a two-player game, record registration, repeated starts, unregistered mining, event cancellation, mining after the end and reset of the second game.
Checklist
I can complete it independentlyMasteredPractice again
Can explain three game states□□
Will connect command events and scheduling□□
Able to navigate normal and failed paths□□

16 / 16

Leave the evidence for the next adventure

Divide "can compile", "number rules pass" and "actual performance of the game is correct" into three columns. Scenarios that are not running are written to be tested; when bugs are discovered, trigger conditions, expected, actual, minimum repairs, and retest results are recorded.

Your verification record
CategoryThe operation you selectedEvidence left behind
NormalA successful path for this lessonVersion and actual output
BorderThe moment before the end, the maximum value or the full backpackCompare item by item with contract
RejectWrong parameters, no permissions or irrelevant eventsThe feedback is clear and the status has not been changed by mistake.
  • Explain why each arrow in this lesson points from here to there; the parallel cards have no sequential meaning.
  • First change a rule, then modify the description and expectations at the same time, and retest with the same input.

TAKE IT WITH YOU

Take the lesson offline

The complete lesson, code, diagrams and exercises, in your preferred language.
