Build Pixel Art with Loops

01 / 12

Two architects, make an appointment first

The village chief wants a house that is 9 blocks wide and 7 blocks high. Ah Xing is responsible for changing floors, and Xiao Li is responsible for walking from left to right on the current floor. If the two go their separate ways, the house will become nothing more than a ball of stone bricks and wool.

The agreement in the program is very clear: the outer loop selects a row, the inner loop completes all the columns of this row, and then changes to a new line. The row numbers of the screen increase downward and the column numbers increase to the right; this is different from the direction of the story of "building a building upwards" and should be based on the coordinate diagram.

• row determines the current row, col determines the current column.
• Every time a row is completed, the inner loop will start again from col = 0.
• Each grid prints one character; println is only responsible for ending the entire line.

02 / 12

How to cooperate with the two layers of circulation

public class L11Example02 {
    public static void main(String[] args) {
        for (int row = 0; row < 2; row++) {
            for (int col = 0; col < 3; col++) {
                System.out.print(row + "," + col + " ");
            }
            System.out.println();
        }
    }
}

0,0 0,1 0,2
1,0 1,1 1,2

03 / 12

Give each grid an address card

The rows and columns all start from 0. The legal row numbers for 4 rows are 0 to 3, and the legal column numbers for 7 columns are 0 to 6. The address of D in the figure is (1,2), and X is the lower right corner (3,6).

public class L11Example03 {
    public static void main(String[] args) {
        for (int row = 0; row < 4; row++) {
            for (int col = 0; col < 7; col++) {
                System.out.print(row == 1 && col == 2 ? "D" : ".");
            }
            System.out.println();
        }
    }
}

.......
..D....
.......
.......

04 / 12

four borders, a circle of walls

public class L11Example04 {
    public static void main(String[] args) {
        int rows = 4, cols = 7;
        for (int row = 0; row < rows; row++) {
            for (int col = 0; col < cols; col++) {
                boolean edge = row == 0 || row == rows - 1
                        || col == 0 || col == cols - 1;
                System.out.print(edge ? "#" : " ");
            }
            System.out.println();
        }
    }
}

#######
#     #
#     #
#######

05 / 12

Let the doors and windows take up space first

The door may be on the bottom edge, and the window may cover the wall. If you check the wall first, the wall will take away these cells. Use if / else if / else to select only one symbol per cell; put more specific door and window conditions before the wall conditions.

06 / 12

symbols also require a material list

Pixel art relies on character width to maintain formation. Select a fixed-width font and half-width symbols; the display width of Chinese, emoticons, and some Unicode symbols may be different. Use only one ASCII character per cell to facilitate accurate acceptance.

public class L11Example06 {
    public static void main(String[] args) {
        for (int row = 0; row < 4; row++) {
            for (int col = 0; col < 6; col++) {
                System.out.print((row + col) % 2 == 0 ? "#" : ".");
            }
            System.out.println();
        }
    }
}

#.#.#.
.#.#.#
#.#.#.
.#.#.#

07 / 12

Building Failure Clinic

public class BadRow {
    public static void main(String[] args) {
        for (int row = 0; row < 2; row++) { }
        System.out.println(row);
    }
}

• The pattern becomes a long column: check if println is put into the inner loop.
• The last column is missing: check the boundary of col < cols and cannot stop at cols - 1 early.
• The right wall can never be drawn: the legal last column is cols - 1, not cols.

08 / 12

Predict first, then allow the computer to speak

public class L11Example08 {
    public static void main(String[] args) {
        for (int row = 0; row < 4; row++) {
            for (int col = 0; col <= row; col++) {
                System.out.print("*");
            }
            System.out.println();
        }
    }
}

*
**
***
****

09 / 12

Challenge Blueprint: Strictly 9 columns and 7 rows

Draw the picture first, then write the conditions. The two rows of roofs occupy columns 2 to 6 of row 0 and columns 1 to 7 of row 1 respectively; doors are located in columns 4 and rows 3 to 5; windows are located in columns 1 or 7 and rows 3 or 4. Row 2 is the upper wall, row 6 is the foundation, and the two side walls are in columns 0 and 8.

• Each line of the house must contain 9 characters, including spaces before and after.
• Judgment order: roof, door, window, wall, space.
• The background space still occupies one grid, and printing cannot be skipped directly.

10 / 12

Complete implementation: one decision per grid

public class PixelHouse {
    public static void main(String[] args) {
        int rows = 7, cols = 9;
        for (int row = 0; row < rows; row++) {
            for (int col = 0; col < cols; col++) {
                char block;
                boolean roof = row == 0 && col >= 2 && col <= 6
                        || row == 1 && col >= 1 && col <= 7;
                boolean door = col == 4 && row >= 3 && row <= 5;
                boolean window = (col == 1 || col == 7)
                        && (row == 3 || row == 4);
                boolean wall = row >= 2 && (row == 2 || row == 6
                        || col == 0 || col == cols - 1);
                if (roof) block = '^';
                else if (door) block = 'D';
                else if (window) block = 'O';
                else if (wall) block = '#';
                else block = ' ';
                System.out.print(block);
            }
            System.out.println();
        }
    }
}

  ^^^^^
 ^^^^^^^
#########
#O  D  O#
#O  D  O#
#   D   #
#########

11 / 12

Use boundary testing for house acceptance

When accepting, count the rows and columns, and then check the key addresses: (0,2) is the roof, (3,4) is the door, (3,1) is the window, and (6,8) is the wall. It's not enough to say it "looks like a house."

• Change col < cols to col <= cols: one more space per line, and restore after finding the cause.
• Move println into the inner layer: explain why each square is on its own line, and then restore it.
• Add torch: Check row == 2 && col == 4 before wall condition, the row should become ####T####.
• Change the rows of the general border example to 1: only one row should be output; do not directly change the coordinates of the fixed house here.

12 / 12

It’s your turn to design the building

• Wooden pick: draw 6×6 hollow border, test 1 row, 2 rows and normal size.
• Iron pick: draw an 8×8 chessboard, and then change it to 9 columns; explain the odd and even conditions.
• Diamond Pickaxe: To design a 9×9 Creeper face, first submit a coordinate sketch, and then write the conditions for the eyes and mouth.

Deliver source code, running patterns, row and column statistics and a bug record. Being able to explain why a coordinate hits a certain symbol is more useful than memorizing the entire code.
